| Nambari ya Sehemu | AM-1280800P4TZQW-T00H |
| Chapa | AMPIRE |
| Ukubwa | 7.0 |
| Maombi | Industrial Outdoor H |
| Azimio | 1280×800 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| chapa | AMPIRE |
| ukubwa wa diagonal | 7.0 inch |
| muundo wa pixel | 1280(RGB)×800 [WXGA] 217PPI |
| eneo la kazi | 149.76(H)×93.6(V) mm |
| eneo la bezel | 152.76(H)×96.6(V) mm |
| mwangaza | 1275 cd/m² (Typ.) |
| tazama mwelekeo | Symmetry |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| rangi ya msaada | 16.7M 50% NTSC |
| uzito | - |
| kiwango cha fremu | 60Hz |
| mfano | AM-1280800P4TZQW-T00H |
| aina | a-Si TFT-LCD , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 162.3(H)×107.9(V) ×11.76(D) mm |
| matibabu | - |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| wakati wa majibu | 35 (Typ.)(Tr+Td) |
| hali ya uendeshaji | SFT, Normally Black, Transmissive |
| chanzo cha mwanga | WLED [5S4P] , 50K hours , With LED Driver |
| iliyoundwa kwa ajili ya | Industrial Outdoor High Brightness |
| jopo la kugusa | PCAP |
