| Nambari ya Sehemu | AM-1280800W2TZQW-00H |
| Chapa | AMPIRE |
| Ukubwa | 10.1 |
| Maombi | Industrial |
| Azimio | 1280×800 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 7S4P |
| Kiolesura | LVDS |
| mtengenezaji | AMPIRE |
| ukubwa wa skrini | 10.1 inch |
| nambari ya pixel | 1280(RGB)×800 (WXGA) 149PPI |
| eneo amilifu(mm) | 216.96 × 135.6 (H×V) |
| eneo la bezel(mm) | - |
| mwangaza | 1000 cd/m² (Typ.) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| mtazamo mzuri | Symmetry |
| kina cha rangi | 16.7M 44% NTSC |
| wingi | 160g (Max.) |
| kiwango cha upya | 60Hz |
| aina ya ishara | LVDS (1 ch, 8-bit) , 40 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| jina la mfano | AM-1280800W2TZQW-00H |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 231 × 154.4 × 7.9 (H×V×D) |
| matibabu | Glare (Haze 0%), Hard coating (3H) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| hali ya kazi | ADS, Normally Black, Transmissive |
| backlight | 7S4P WLED , 50K hours , No Driver |
| kutumika kwa | Industrial |
| skrini ya kugusa | Without |
