| Nambari ya Sehemu | AV080WSM-NW2 |
| Chapa | BOE |
| Ukubwa | 8.0 |
| Maombi | Automotive Display |
| Azimio | 1024×600 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | 3S10P |
| Kiolesura | LVDS |
| mtengenezaji | BOE |
| jina la mfano | AV080WSM-NW2 |
| ukubwa wa skrini | 8.0 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 1024(RGB)×600 (WSVGA) 148PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 176.64 × 99.36 (H×V) |
| muhtasari(mm) | 192.8 × 116.9 × 4.7 (H×V×D) |
| eneo la bezel(mm) | 180.1 × 103.4 (H×V) |
| matibabu | - |
| mwangaza | 600 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | ADS, Normally Black, Transmissive |
| kina cha rangi | 262K/16.7M 50% NTSC |
| backlight | 3S10P WLED , 30K hours , No Driver |
| wingi | 176/180g (Typ./Max.) |
| kutumika kwa | Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 6/8-bit) , FPC 40 pins |
| usambazaji wa voltage | 3.3/11.5/21/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
