| Nambari ya Sehemu | C090EAN04.1 |
| Chapa | AUO |
| Ukubwa | 9.0 |
| Maombi | Outdoor High Brightn |
| Azimio | 1280×720 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | AUO |
| mfano | C090EAN04.1 |
| ukubwa wa diagonal | 9.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1280(RGB)×720 [WXGA] 163PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 198.72(H)×111.78(V) mm |
| muhtasari dim. | 212.2(H)×127.9(V) ×11(D) mm |
| eneo la bezel | 202.02(H)×115.78(V) mm |
| matibabu | Antiglare |
| mwangaza | 900 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| hali ya uendeshaji | AHVA, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 72% NTSC |
| chanzo cha mwanga | WLED [8S3P] , 10K hours , W/O Driver |
| uzito | TBD |
| iliyoundwa kwa ajili ya | Outdoor High Brightness Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 8-bit) , 40 pins FPC |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
