| Nambari ya Sehemu | C100HAT01.0 |
| Chapa | AUO |
| Ukubwa | 10.0 |
| Maombi | Automotive Display |
| Azimio | 1560×700 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| mtengenezaji | AUO |
| jina la mfano | C100HAT01.0 |
| ukubwa wa skrini | 10.0 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 1560(RGB)×700 171PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 231.66 × 103.95 (H×V) |
| muhtasari(mm) | 259.36 × 131.32 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Antiglare, Antireflection |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| majibu | 30 (Max.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | AHVA, Normally Black, Transmissive |
| kina cha rangi | 16.7M |
| backlight | WLED |
| wingi | 375±38g |
| kutumika kwa | Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | - |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
