| Nambari ya Sehemu | SVA101WV1(01TA)(A) |
| Chapa | SVA-NEC |
| Ukubwa | 10.0 |
| Maombi | NOPC |
| Azimio | 1024×576 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 400:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | SVA-NEC |
| mfano wa paneli | SVA101WV1(01TA)(A) |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.0 inch |
| azimio | 1024(RGB)×576 , WSVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 221.184×124.416 mm |
| muhtasari | 235×143×5.2 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 400:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193145% |
| wakati wa majibu | 8 (Typ.)(Tr+Td) |
| angle ya kutazama | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | NOPC |
| HSD100PXN1-A00 | HannStar | 10.0 | 1024×768 |
| HSD100PXN1-A00-C11 | HannStar | 10.0 | 1024×768 |
| LM100SS1T522 | SHARP | 10.0 | 800×600 |
| LT100AA40000 | TOSHIBA | 10.0 | 800×600 |
| PM100WX2 | E Ink | 10.0 | 800×480 |
| PW100XS1 | E Ink | 10.0 | 640×468 |
| PW100XS5 | E Ink | 10.0 | 640×468 |
| SVA101WV1(01TA)(A) | SVA-NEC | 10.0 | 1024×576 |
| SX25S004 | KOE | 10.0 | 800×600 |
| TM100SV-A02-01 | SANYO | 10.0 | 800×600 |
| A089SW01 V0 | AUO | 8.9 | 1024×600 |
| AT102TN42 | Innolux | 10.2 | 1024×600 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| BA101WS1-100 | BOE | 10.1 | 1024×600 |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| LP101WS1-TLB1 | LG Display | 10.1 | 1024×576 |
| LP116WH1-TLN1 | LG Display | 11.6 | 1366×768 |
| M101NWT2 R2 | IVO | 10.1 | 1024×600 |
| N101L6-L0C | Innolux | 10.1 | 1024×600 |
| N116BGE-L32 | Innolux | 11.6 | 1366×768 |
