| Nambari ya Sehemu | CLAA104XA12BW |
| Chapa | CPT |
| Ukubwa | 10.4 |
| Maombi | IA |
| Azimio | 1024×768 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | CPT |
| mfano wa paneli | CLAA104XA12BW |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.4 inch |
| azimio | 1024(RGB)×768 , XGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 211.2×158.4 mm |
| muhtasari | 236×174.3×7.4 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193147% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 55/65/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 3S13PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
| CLAA101FP01 | CPT | 10.1 | 1920×1200 |
| CLAA101NA0ACN | CPT | 10.1 | 1024×576 |
| CLAA101NC05 | CPT | 10.1 | 1024×600 |
| CLAA101WA01A | CPT | 10.1 | 1366×768 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| CLAA102NA0ACG | CPT | 10.2 | 1024×600 |
| CLAA102NA1BCN | CPT | 10.2 | 1024×600 |
| CLAA102NB01XV | CPT | 10.2 | 1024×600 |
| CLAA104XA02CW | CPT | 10.4 | 1024×768 |
| A101AIE40L0 | Aptus | 10.1 | 1280×720 |
| AA121SL03 | Mitsubishi | 12.1 | 800×600 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| F-55472GNFJ-SLW-AAN | Kyocera | 2.8 | 128×64 |
| KCS057QV1AJ-G20 | Kyocera | 5.7 | 320×240 |
| LQ084V1DG21 | SHARP | 8.4 | 640×480 |
| LT084AC27800 | TOSHIBA | 8.4 | 800×600 |
| NL6448AC33-18A | NLT | 10.4 | 640×480 |
| TM104SCH02 | Tianma | 10.4 | 800×600 |
| TX18D30VM2FAA | KOE | 7.0 | 800×480 |
