| Nambari ya Sehemu | TM104SCH02 |
| Chapa | Tianma |
| Ukubwa | 10.4 |
| Maombi | IA |
| Azimio | 800×600 |
| Muundo | LCM |
| Mwangaza | 230 |
| CR | 400:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM104SCH02 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.4 inch |
| azimio | 800(RGB)×600 , SVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 211.2×158.4 mm |
| muhtasari | 236×176.9 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 230 cd/m² (Typ.) |
| uwiano wa utofautishaji | 400:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| wakati wa majibu | 10/15 (Typ.)(Tr/Td) |
| angle ya kutazama | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
| AA104SL02-DE1 | Mitsubishi | 10.4 | 800×600 |
| G104X1-L02 | Innolux | 10.4 | 1024×768 |
| LQ104V1DG62 | SHARP | 10.4 | 640×480 |
| NL8060BC26-11 | NLT | 10.4 | 800×600 |
| TM104QDSG09 | Tianma | 10.4 | 640×480 |
| TM104SBH01 | Tianma | 10.4 | 800×600 |
| TM104SCH02 | Tianma | 10.4 | 800×600 |
| TM104SDH01 | Tianma | 10.4 | 800×600 |
| TM104SDH02 | Tianma | 10.4 | 800×600 |
| TM104SDHG30 | Tianma | 10.4 | 800×600 |
| AA070ME01 | Mitsubishi | 7.0 | 800×480 |
| AC150XA01 | Mitsubishi | 15.0 | 1024×768 |
| G150XG03 V2 | AUO | 15.0 | 1024×768 |
| KCS6448HSTT-X3 | Kyocera | 10.4 | 640×480 |
| LCBHBT161M | NAN YA | 5.7 | 320×240 |
| LM240WU8-SLA2 | LG Display | 24.0 | 1920×1200 |
| LM64C35P | SHARP | 10.4 | 640×480 |
| SX19V007 | KOE | 7.5 | 640×480 |
| TCG058QVLAA-G00 | Kyocera | 5.8 | 320×240 |
| TX54D11VC0CAB | JDI | 21.3 | 1600×1200 |
