| Nambari ya Sehemu | HSD090JFW1-A02 |
| Chapa | HannStar |
| Ukubwa | 9.0 |
| Maombi | Automotive Display |
| Azimio | 1024×600 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | 3S13P |
| Kiolesura | LVDS |
| mtengenezaji | HannStar |
| jina la mfano | HSD090JFW1-A02 |
| ukubwa wa skrini | 9.0 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 1024(RGB)×600 (WSVGA) 132PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 196.608 × 114.15 (H×V) |
| muhtasari(mm) | 211.1 × 126.5 × 6 (H×V×D) |
| eneo la bezel(mm) | 200.01 × 117.55 (H×V) |
| matibabu | Antiglare, Hard coating (3H) |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 17/18 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | IPS Pro, Normally Black, Transmissive |
| kina cha rangi | 16.2M 50% NTSC |
| backlight | 3S13P WLED , 15K hours , No Driver |
| wingi | 226g (Typ.) |
| kutumika kwa | Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 8-bit) , FPC 40 pins |
| usambazaji wa voltage | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
