| Nambari ya Sehemu | HSD170ME13-A04 |
| Chapa | HannStar |
| Ukubwa | 17.0 |
| Maombi | DMPC |
| Azimio | 1280×1024 |
| Muundo | LCM |
| Mwangaza | 270 |
| CR | 500:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | HannStar |
| mfano wa paneli | HSD170ME13-A04 2 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 17.0 inch |
| azimio | 1280(RGB)×1024 , SXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 337.92×270.336 mm |
| muhtasari | 358.5×296.5 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 270 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 16.2M (6-bit + FRC) |
| wakati wa majibu | 4/8 (Typ.)(Tr/Td) |
| angle ya kutazama | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | DMPC |
| B170PW01 V1 | AUO | 17.0 | 1440×900 |
| HSD170ME13-A04 | HannStar | 17.0 | 1280×1024 |
| HSD170ME13-A05 | HannStar | 17.0 | 1280×1024 |
| HSD170MGW1-A00 | HannStar | 17.0 | 1440×900 |
| HSD170MGW1-B00 | HannStar | 17.0 | 1440×900 |
| HSD170MGW1-B01 | HannStar | 17.0 | 1440×900 |
| L170E3 EC-5 | AUO | 17.0 | 1280×1024 |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLH1 | LG Display | 17.0 | 1280×1024 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
| A190EN02 V0 | AUO | 19.0 | 1280×1024 |
| HT15X15-D01 | HYDIS | 15.0 | 1024×768 |
| ITSX98 | IDTech | 18.1 | 1280×1024 |
| LQ150X1DG11 | SHARP | 15.0 | 1024×768 |
| LTM215HT05 | Samsung | 21.5 | 1920×1080 |
| M170E8-L01 | Innolux | 17.0 | 1280×1024 |
| M240UW04 V0 | AUO | 24.0 | 1920×1200 |
| MT200LW02 V.0 | Innolux | 20.0 | 1600×900 |
| MT220WW01 V.6 | Innolux | 22.0 | 1680×1050 |
| MV236FHB-N10 | BOE | 23.6 | 1920×1080 |
