LM170E03-TLH1

LM170E03-TLH1
LM170E03-TLH1
LM170E03-TLH1 thumb LM170E03-TLH1 thumb
Chapa
LG Display
Ukubwa
17.0
Maombi
DMPC
Azimio
1280×1024
Muundo
LCM
Mwangaza
250
CR
800:1
Rangi
16.7M
Mwangaza nyuma
CCFL
Kiolesura
LVDS
In Stock
1410
Vipimo

Nambari ya Sehemu LM170E03-TLH1
ChapaLG Display
Ukubwa17.0
MaombiDMPC
Azimio1280×1024
MuundoLCM
Mwangaza250
CR800:1
Rangi16.7M
Mwangaza nyumaCCFL
KiolesuraLVDS
chapa ya paneliLG Display
mfano wa paneliLM170E03-TLH1 3 Compatible model
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli17.0 inch
azimio1280(RGB)×1024 , SXGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi337.92×270.336 mm
muhtasari358.5×296.5×16.5 mm
usoAntiglare, Hard coating (3H)
mwangaza250 cd/m² (Typ.)
uwiano wa utofautishaji800:1 (Typ.)
kuonyesha rangi16.7M (6-bit + Hi-FRC)
wakati wa majibu1.2/3.8 (Typ.)(Tr/Td)
angle ya kutazama85/85/75/85 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa2 pcsCCFLWithout Driver
kiolesura cha isharaLVDS (2 ch, 8-bit), 30 pins
voltage ya pembejeo5.0V (Typ.)
maombiDMPC
