| Nambari ya Sehemu | HX121WX1-100 |
| Chapa | HYDIS |
| Ukubwa | 12.1 |
| Maombi | PAD |
| Azimio | 1280×800 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 700:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | BOE HYDIS |
| mfano wa paneli | HX121WX1-100 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 12.1 inch |
| azimio | 1280(RGB)×800 , WXGA |
| hali ya kuonyesha | AFFS, Normally Black, Transflective |
| eneo la kazi | 261.12×163.2 mm |
| muhtasari | 276.8×180×6.8 mm |
| uso | Hard coating (2H), Antireflection |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.)(Transmissive) |
| kuonyesha rangi | 262K (6-bit), CIE193142% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 90/90/90/90 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 12S4PWLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
| AA121SP01 | Mitsubishi | 12.1 | 800×600 |
| HX121WX1-100 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-101 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-103 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-110 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| M121MNS1 R1 | IVO | 12.1 | 800×600 |
| N121I7-L01 | Innolux | 12.1 | 1280×800 |
| NL8060BC31-02 | NLT | 12.1 | 800×600 |
| TM121SV-A01 | SANYO | 12.1 | 800×600 |
| AMS767KC04-1 | Samsung | 7.7 | 1280×800 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| HV121WX5-114 | HYDIS | 12.1 | 1280×800 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| LQ070S1DW01 | SHARP | 7.0 | 600×800 |
| LTL101DL03-T01 | Samsung | 10.1 | 2560×1600 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| TV096WXM-NS0 | BOE | 9.6 | 800×1280 |
