| Nambari ya Sehemu | LQ070T5BG01 |
| Chapa | SHARP |
| Ukubwa | 7.0 |
| Maombi | VDP |
| Azimio | 480×234 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 60:1 |
| Rangi | Full color |
| Mwangaza nyuma | CCFL |
| Kiolesura | Analog |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ070T5BG01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 480(RGB)×234 |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 155.52×87.75 mm |
| muhtasari | 173×106 mm |
| uso | Antiglare |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 60:1 (Min.) |
| kuonyesha rangi | Full color |
| wakati wa majibu | 30/50 (Typ.)(Tr/Td) |
| angle ya kutazama | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 2 pcsCCFLWithout Driver |
| kiolesura cha ishara | Analog RGB + Composite Video (NTSC/PAL), 24 pins |
| voltage ya pembejeo | 5.3/13/-16V (VSH/VGH/VGL) |
| maombi | VDP |
| LQ070M1SX01 | SHARP | 7.0 | 1200×1920 |
| LQ070S1DW01 | SHARP | 7.0 | 600×800 |
| LQ070T5AR01 | SHARP | 7.0 | 480×234 |
| LQ070T5DG30 | SHARP | 7.0 | |
| LQ070T5DR02 | SHARP | 7.0 | 480×240 |
| LQ070Y1LG12 | SHARP | 7.0 | 800×480 |
| LQ070Y3DG02 | SHARP | 7.0 | 800×480 |
| LQ070Y5DA02A | SHARP | 7.0 | 800×480 |
| LQ070Y5DG30 | SHARP | 7.0 | 800×480 |
| LQ070Y5DR04 | SHARP | 7.0 | 800×480 |
| A070FW03 V4 | AUO | 7.0 | 480×234 |
| AT056TN03 | Innolux | 5.6 | 320×234 |
| AT070TN07 V.A | Innolux | 7.0 | 480×234 |
| DLC0500AIG-2 | Other | 5.0 | 640×480 |
| HSD070I651-F20 | HannStar | 7.0 | 480×234 |
| LQ070T5BG01 | SHARP | 7.0 | 480×234 |
| LR700BA9005 | Innolux | 7.0 | 480×234 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
| TM056KDH01 | Tianma | 5.6 | 320×234 |
| TM056KDH02 | Tianma | 5.6 | 320×234 |
