| Nambari ya Sehemu | LTA120W1-T02 |
| Chapa | Samsung |
| Ukubwa | 12.0 |
| Maombi | DPF |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 300:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | TTL |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | LTA120W1-T02 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 12.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 261.6×156.96 mm |
| muhtasari | 281.3×171.4 mm |
| uso | |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | |
| angle ya kutazama | |
| aina ya taa | 2 pcsCCFL |
| kiolesura cha ishara | TTL (1 ch, 6-bit) |
| rohs: | |
| maombi | DPF |
