M201UN04 V0


Chapa
AUO
Ukubwa
20.1
Maombi
DMPC
Azimio
1600×1200
Muundo
LCM
Mwangaza
300
CR
800:1
Rangi
16.7M
Mwangaza nyuma
CCFL
Kiolesura
LVDS
In Stock
276
Vipimo

Nambari ya Sehemu M201UN04 V0
ChapaAUO
Ukubwa20.1
MaombiDMPC
Azimio1600×1200
MuundoLCM
Mwangaza300
CR800:1
Rangi16.7M
Mwangaza nyumaCCFL
KiolesuraLVDS
chapa ya paneliAUO
mfano wa paneliM201UN04 V0
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli20.1 inch
azimio1600(RGB)×1200 , UXGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi408×306 mm
muhtasari432×331.5×25.5 mm
usoAntiglare, Hard coating (3H)
mwangaza300 cd/m² (Typ.)
uwiano wa utofautishaji800:1 (Typ.)
kuonyesha rangi16.7M (6-bit + Hi-FRC), CIE193172%
wakati wa majibu4.5/1.5 (Typ.)(Tr/Td)
angle ya kutazama80/80/80/80 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa4 pcsCCFLWithout Driver
kiolesura cha isharaLVDS (2 ch, 8-bit), 30 pins
voltage ya pembejeo5.0V (Typ.)
maombiDMPC
