| Nambari ya Sehemu | TM070RDSG12 |
| Chapa | TIANMA |
| Ukubwa | 7.0 |
| Maombi | Industrial |
| Azimio | 800×480 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | 7S3P |
| Kiolesura | |
| mtengenezaji | TIANMA |
| jina la mfano | TM070RDSG12 |
| ukubwa wa skrini | 7.0 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 800(RGB)×480 (WVGA) 133PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 152.4 × 91.44 (H×V) |
| muhtasari(mm) | 167 × 106.3 × 9.8 (H×V×D) |
| eneo la bezel(mm) | 154.4 × 93.44 (H×V) |
| matibabu | Antiglare |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 20 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | SFT, Normally Black, Transmissive |
| kina cha rangi | 262K/16.7M 70% NTSC |
| backlight | 7S3P WLED , 50K hours , With LED Driver |
| wingi | 175g (Typ.) |
| kutumika kwa | Industrial |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
