| Nambari ya Sehemu | TM070SDH03 |
| Chapa | Tianma |
| Ukubwa | 7.0 |
| Maombi | DPF |
| Azimio | 800×600 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM070SDH03 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800(RGB)×600 , SVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 141×105.75 mm |
| muhtasari | 155.5×118.7×3.7 mm |
| uso | Antiglare |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K , CIE193150% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 3S6PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | DPF |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
| TM070DDH08 | Tianma | 7.0 | 1024×600 |
| TM070DDH09 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TM070SDH03 | Tianma | 7.0 | 800×600 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
| A070SN01 V3 | AUO | 7.0 | 800×600 |
| A070SN02 V0 CELL | AUO | 7.0 | 800×600 |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| AT070TN01 | Innolux | 7.0 | 480×234 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
| HSD101PFW3-B00 | HannStar | 10.1 | 1024×600 |
| LD050WQ1-TD02 | LG Display | 5.0 | 480×272 |
| LQ070Y3DG02 | SHARP | 7.0 | 800×480 |
| LQ085Y3DG12 | SHARP | 8.5 | 800×480 |
| TM104SDHG30 | Tianma | 10.4 | 800×600 |
