| Nambari ya Sehemu | TM104TDGP10 |
| Chapa | TIANMA |
| Ukubwa | 10.4 |
| Maombi | Industrial |
| Azimio | 1024×768 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | 8S4P |
| Kiolesura | LVDS |
| chapa ya paneli | TIANMA |
| saizi ya paneli | 10.4" |
| azimio | 1024(RGB)×768, XGA, 123PPI |
| eneo la maonyesho | 210.432(W)×157.824(H) mm |
| saizi ya muhtasari | 230(W)×175.8(H) ×9.06(D) mm |
| mwangaza | 450 cd/m² (Typ.) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| mwonekano bora zaidi | Symmetry |
| kuonyesha rangi | 262K/16.7M 50% NTSC |
| masafa | 60Hz |
| uzito wa paneli | 430g (Typ.) |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| mfano wa paneli | TM104TDGP10 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 213.43(W)×160.82(H) mm |
| uso | Antiglare |
| uwiano wa utofautishaji | 1200:1 (Typ.) (TM) |
| hali ya kuonyesha | SFT, Normally Black, Transmissive |
| wakati wa majibu | 35 (Typ.)(Tr+Td) |
| aina ya taa | 8S4P WLED , With LED Driver |
| skrini ya kugusa | Without |
| maombi | Industrial |
| LB104S01-TL02 | LG Display | 10.4 | 800×600 |
| LQ104V1DW02 | SHARP | 10.4 | 640×480 |
| LQ10D131 | SHARP | 10.4 | 640×480 |
| LTM10C348F | TOSHIBA | 10.4 | 800×600 |
| TM104QDSG09 | Tianma | 10.4 | 640×480 |
| TM104SBH01 | Tianma | 10.4 | 800×600 |
| TM104SCH02 | Tianma | 10.4 | 800×600 |
| TM104SDH01 | Tianma | 10.4 | 800×600 |
| TM104SDH02 | Tianma | 10.4 | 800×600 |
| TM104SDHG30 | Tianma | 10.4 | 800×600 |
