| Nambari ya Sehemu | HSD100PXN1-A00-C40 |
| Chapa | HannStar |
| Ukubwa | 10.0 |
| Maombi | PAD |
| Azimio | 1024×768 |
| Muundo | Assembly |
| Mwangaza | 180 |
| CR | 600:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | HannStar |
| mfano wa paneli | HSD100PXN1-A00-C40 |
| aina ya paneli | a-Si TFT-LCD , Assembly |
| saizi ya paneli | 10.0 inch |
| azimio | 1024(RGB)×768 , XGA |
| eneo la kazi | 202.752×152.064 mm |
| muhtasari | 243.8×190.8×7.4 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 180 cd/m² (Typ.) |
| uwiano wa utofautishaji | 600:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| angle ya kutazama | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
