| Nambari ya Sehemu | C084XAN01.0 |
| Chapa | AUO |
| Ukubwa | 8.4 |
| Maombi | Automotive Display |
| Azimio | 1024×768 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| mtengenezaji | AUO |
| ukubwa wa skrini | 8.4 inch |
| nambari ya pixel | 1024(RGB)×768 (XGA) 152PPI |
| eneo amilifu(mm) | 170.496 × 127.872 (H×V) |
| mwangaza | - |
| angle ya kutazama | - |
| mtazamo mzuri | Symmetry |
| kina cha rangi | 16.7M |
| wingi | - |
| kiwango cha upya | 60Hz |
| aina ya ishara | LVDS (1 ch, 8-bit) , 40 pins Connector |
| max. ukadiriaji | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| jina la mfano | C084XAN01.0 |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | - |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| majibu | 30 (Max.)(Tr+Td) ms |
| hali ya kazi | AHVA, Normally Black, Transmissive |
| backlight | WLED |
| kutumika kwa | Automotive Display |
| skrini ya kugusa | Without |
