| Nambari ya Sehemu | HSD090ICW1-A00 |
| Chapa | HannStar |
| Ukubwa | 9.0 |
| Maombi | DPF |
| Azimio | 640×234 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 500:1 |
| Rangi | |
| Mwangaza nyuma | WLED |
| Kiolesura | Analog |
| chapa ya paneli | HannStar |
| mfano wa paneli | HSD090ICW1-A00 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.0 inch |
| azimio | 640(RGB)×234 |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 197.76×111.735 mm |
| muhtasari | 210.7×126.4×4.25 mm |
| uso | |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | , CIE193145% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/70/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 3S8PWLEDWithout Driver |
| kiolesura cha ishara | TFT Specific Analog RGB, 26 pins |
| voltage ya pembejeo | 3.3/5/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL) |
| maombi | DPF |
