| Nambari ya Sehemu | LQ070T5DG01 |
| Chapa | SHARP |
| Ukubwa | 7.0 |
| Maombi | CNS |
| Azimio | 854×480 |
| Muundo | LCM |
| Mwangaza | 410 |
| CR | 60:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | TTL |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ070T5DG01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 854(RGB)×480 , FWVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 155×87.12 mm |
| muhtasari | 176.9×109.3 mm |
| uso | Antiglare |
| mwangaza | 410 cd/m² (Typ.) |
| uwiano wa utofautishaji | 60:1 (Min.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 30/50 (Typ.)(Tr/Td) |
| angle ya kutazama | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 31 pins |
| voltage ya pembejeo | 5/10/-10V (Typ.)(VSH/VGH/VGL) |
| maombi | CNS |
