| Nambari ya Sehemu | TX23D86VM0BAA |
| Chapa | KOE |
| Ukubwa | 9.0 |
| Maombi | IA |
| Azimio | 1280×768 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | HITACHI |
| mfano wa paneli | TX23D86VM0BAA |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.0 inch |
| azimio | 1280(RGB)×768 , WXGA |
| hali ya kuonyesha | IPS NP, Normally Black, Transmissive |
| eneo la kazi | 193.92×116.352 mm |
| muhtasari | 216×142 mm |
| uso | |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193172% |
| wakati wa majibu | 22 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
