| Nambari ya Sehemu | LTM170EI-A01 |
| Chapa | Samsung |
| Ukubwa | 17.0 |
| Maombi | DMPC |
| Azimio | 1280×1024 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 350:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | CCFL |
| Kiolesura | Analog |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | LTM170EI-A01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 17.0 inch |
| azimio | 1280(RGB)×1024 , SXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 337.92×270.336 mm |
| muhtasari | 383.5×298.6×19.5 mm |
| uso | Antiglare (Haze 25%), Hard coating (3H) |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 350:1 (Typ.) |
| kuonyesha rangi | 16.2M (6-bit + FRC), CIE193165% |
| wakati wa majibu | 5/20 (Typ.)(Tr/Td) |
| angle ya kutazama | 75/75/65/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 pcsCCFLEmbedded (Inverter) |
| kiolesura cha ishara | Analog RGB, 27 pins |
| maombi | DMPC |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L21 | Samsung | 17.0 | 1280×1024 |
| LTM170EI-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170ET01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L21 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTM170W1-L01 | Samsung | 17.0 | 1280×768 |
| CLAA170ES01E | CPT | 17.0 | 1280×1024 |
| LM150X08-A4K3 | LG Display | 15.0 | 1024×768 |
| LM190WX1-TLA1 | LG Display | 19.0 | 1440×900 |
| LM201W01-B6K1 | LG Display | 20.1 | 1680×1050 |
| LM270WF5-SLA1 | LG Display | 27.0 | 1920×1080 |
| LM300W01-STA1 | LG Display | 30.0 | 2560×1600 |
| M170EG01 V9 | AUO | 17.0 | 1280×1024 |
| M185BGE-L10 | Innolux | 18.5 | 1366×768 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| MT190AW01 V.C | Innolux | 19.0 | 1440×900 |
