| Nambari ya Sehemu | LTM230TT01 |
| Chapa | Samsung |
| Ukubwa | 23.0 |
| Maombi | DMPC |
| Azimio | 2048×1152 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | LTM230TT01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 23.0 inch |
| azimio | 2048(RGB)×1152 , WDXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 509.952×286.848 mm |
| muhtasari | 531.4×310 mm |
| uso | Antiglare (Haze 25%), Hard coating (3H) |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193172% |
| wakati wa majibu | 5 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | DMPC |
