| Nambari ya Sehemu | M080AWT8 R1 |
| Chapa | IVO |
| Ukubwa | 8.0 |
| Maombi | Automotive Display |
| Azimio | 1024×600 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | IVO |
| mfano | M080AWT8 R1 |
| ukubwa wa diagonal | 8.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1024(RGB)×600 [WSVGA] 148PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 176.64(H)×99.36(V) mm |
| muhtasari dim. | 192.8(H)×116.9(V) ×8.35(D) mm |
| eneo la bezel | 178.84(H)×101.56(V) mm |
| matibabu | Antiglare |
| mwangaza | 670 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| tazama mwelekeo | 6 o'clock |
| wakati wa majibu | 16 (Typ.)(Tr+Td) |
| angle ya kutazama | 75/75/70/75 (Typ.)(CR≥10) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| rangi ya msaada | 262K/16.7M 72% NTSC |
| chanzo cha mwanga | WLED [3S7P] , 30K hours , W/O Driver |
| uzito | 240g (Max.) |
| iliyoundwa kwa ajili ya | Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
