| Nambari ya Sehemu | M090AWP4 R1 |
| Chapa | IVO |
| Ukubwa | 9.0 |
| Maombi | Outdoor High Brightn |
| Azimio | 800×480 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 700:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| mtengenezaji | IVO |
| ukubwa wa skrini | 9.0 inch |
| nambari ya pixel | 800(RGB)×480 (WVGA) 104PPI |
| eneo amilifu(mm) | 198 × 112.08 (H×V) |
| eneo la bezel(mm) | 200.2 × 114.28 (H×V) |
| mwangaza | 750 cd/m² (Typ.) |
| angle ya kutazama | 70/70/50/70 (Typ.)(CR≥10) |
| mtazamo mzuri | 6 o'clock |
| kina cha rangi | 262K 70% NTSC |
| wingi | - |
| kiwango cha upya | 60Hz |
| aina ya ishara | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| max. ukadiriaji | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| jina la mfano | M090AWP4 R1 |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 210.82 × 126.96 × 6.4 (H×V×D) |
| matibabu | Antiglare, Hard coating (3H) |
| uwiano wa utofautishaji | 700 : 1 (Typ.) (TM) |
| majibu | 12 (Typ.)(Tr+Td) ms |
| hali ya kazi | TN, Normally White, Transmissive |
| backlight | WLED , No Driver |
| kutumika kwa | Outdoor High Brightness Automotive Display |
| skrini ya kugusa | Without |
