| Nambari ya Sehemu | P101DEA-AZ0 |
| Chapa | Innolux |
| Ukubwa | 10.1 |
| Maombi | Pad & Tablet |
| Azimio | 800×1280 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 4 |
| Kiolesura | MIPI |
| mtengenezaji | Innolux |
| jina la mfano | P101DEA-AZ0 |
| ukubwa wa skrini | 10.1 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 800(RGB)×1280 (WXGA) 150PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 135.36 × 216.576 (H×V) |
| muhtasari(mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Glare (Haze 0%), Hard coating |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 80/80/80/80 (Min.)(CR≥10) |
| majibu | 35 (Max.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | AAS, Normally Black, Transmissive |
| kina cha rangi | 16.7M 60% NTSC |
| backlight | 4 strings WLED , 15K hours , No Driver |
| wingi | 175g (Max.) |
| kutumika kwa | Pad & Tablet |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | MIPI (4 data lanes) , Connector 40 pins |
| usambazaji wa voltage | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| max. ukadiriaji | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
