| Nambari ya Sehemu | TX20D207VM0AAA |
| Chapa | KOE |
| Ukubwa | 8.0 |
| Maombi | Industrial Automotiv |
| Azimio | 1280×768 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1400:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | KOE |
| mfano wa paneli | TX20D207VM0AAA |
| saizi ya paneli | 8.0" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1280(RGB)×768, WXGA, 186PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 173.952(W)×104.371(H) mm |
| ufunguzi wa bezel | 177.0(W)×107.4(H) mm |
| saizi ya muhtasari | 189.5(W)×119.4(H) ×12.1(D) mm |
| uso | - |
| mwangaza | 1200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1400:1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 19 (Typ.)(Tr+Td) |
| kuonyesha rangi | 16.7M 70% NTSC |
| aina ya taa | WLED , 70K hours , With LED Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | 254g (Typ.) |
| maombi | Industrial Automotive Display |
| kiolesura cha ishara | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
