| Nambari ya Sehemu | LSL080AL02-002 |
| Chapa | Samsung |
| Ukubwa | 8.0 |
| Maombi | PAD |
| Azimio | 800×1280 |
| Muundo | CELL |
| Mwangaza | 0 |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No B/L |
| Kiolesura | MIPI |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | LSL080AL02-002 |
| aina ya paneli | a-Si TFT-LCD , CELL |
| saizi ya paneli | 8.0 inch |
| azimio | 800(RGB)×1280 , WXGA |
| hali ya kuonyesha | PLS, Normally Black, Transmissive |
| eneo la kazi | 107.64×172.224 mm |
| muhtasari | 112.64×181.824×0.69 mm |
| uso | Glare (Haze 0%), Hard coating |
| kioo kina | 0.20+0.20 mm |
| uhamishaji | 6.6% (Typ.)(with Polarizer) |
| uwiano wa utofautishaji | 900:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit) |
| wakati wa majibu | 16 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| kiolesura cha ishara | MIPI (4 data lanes), 34 pins |
| voltage ya pembejeo | 1.8/3.3V (Typ.)(DVDD/PVDD) |
| maombi | PAD |
